B/W Ultrasound

Location£ºHome > Products > B/W Ultrasound >



Technical Specification
Display size:     15 inch TFT
Scanning manner:   Electronic convex array, electronic linear array
Working frequency: 2.0MHz~10MHz
Display mode: B, B+B, B+M, M, 4B
Scanning range:       Convex array 60°~150°
Amplification factor:        1.0, 1.2, 1.5,2.0
Gain control:    8 segments TGC and overall gain can be adjusted respectively
Image processing:  8 γ corrections, frame correlation, point correlation, line correlation, digital filtering, digital  edge enhancement and pseudo color processing, etc
Image gray-scale:   256 levels
Scanning line number:     512 lines/frame
Frame rate:      30 frames/second
Digital scanning conversion:   512×512×8 bits
Memory capacity:   ≥2GB
Conventional measurements: distance, perimeter, area, volume
Obstetric measurement  gestational weeks (BPD, GS, CRL, FL, HL, OFD, TTD, AC), expected date of confinement and fetus weight, etc.
Report function:       auto make report
Battery capacity:      3000mAH/7.4V,can work more than 2 hours
Display screen:        15" TFT
Output interface:     USB port, video
Overall size:     362mm×340mm×60mm
Total weight:    4Kg(with battery)
